8573/15-200, 16 A compact flange socket, 20 ... 25 V AC Violet, 2 P, 0 h, Polyamide, Zone 1, 2, 21, 22
- Product Type: 8573/15-200
- Art. No.: 241379
Technical data
General
| MY R. STAHL | 8573A |
| Product Type | 8573/15-200 |
| Highlights | Zones 1, 2, 21 and 22, degree of protection IP66, extreme temperature range of -50 to +60 °CFull AC-3 switching capacity according to IEC/EN 60947-3Wear-free contacts protected against corrosion, even in a corrosive atmosphere |
| Functional Description | R. STAHL Series 8573/15 16 A flange sockets are suitable for 2- or 3-pole applications up to voltages of 50 V. Self-cleaning lamellar contacts provide optimum contact. The integrated rotary switch mechanism and the integrated locking device reliably prevent disconnection under load. |
Explosion Protection
Electrical Data
Device Specific Data
Ambient Conditions
Mechanical Data
Mounting / Installation
Components
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| Flange Socket Series 8573/15 | Data Sheet |
 |
|
| Flange Socket Series 8573/15 | Data Sheet |
 |
|
| 16 A compact flange socket Extra-low voltage Flange socket - 8573/15-200 - 241379 - de-DE | Single Data Sheet |
|
|
| 16 A compact flange socket Extra-low voltage Flange socket - 8573/15-200 - 241379 - en-GB | Single Data Sheet |
|
|
| 16 A compact flange socket Extra-low voltage Flange socket - 8573/15-200 - 241379 - es-ES | Single Data Sheet |
 |
|
| 16 A compact flange socket Extra-low voltage Flange socket - 8573/15-200 - 241379 - es-ES | Single Data Sheet |
|
|
| 16 A compact flange socket Extra-low voltage Flange socket - 8573/15-200 - 241379 - fr-FR | Single Data Sheet |
 |
|
| 16 A compact flange socket Extra-low voltage Flange socket - 8573/15-200 - 241379 - fr-FR | Single Data Sheet |
|
