8573/13-210, 16 A compact wall-mounting socket, 20 ... 25 V DC Violet, 2 P, 10 h, M25 x 1.5, 7 - 17 mm, Polyamide, Zone 1, 2, 21, 22
- Product Type: 8573/13-210
- Art. No.: 243173
Technical data
General
| MY R. STAHL | 8573B |
| Product Type | 8573/13-210 |
| Product description | 16 A compact wall-mounting socket Extra-low voltage |
| Highlights | Compact designLarge temperature range of useHigh mechanical impact and shock resistancePerfect protection against penetration of liquids and dusts3D data for download on the website |
| Functional Description | The sockets of the new R. STAHL Series 8573/13 are for 2- or 3-pole applications up to 16 A. The compact sockets for extra-low voltages up to 50 V are made from robust and chemical-resistant plastics. Self-cleaning lamellar contacts provide optimum contact. The integrated rotary switch mechanism and the integrated locking device reliably prevent the plugs from disconnecting under load.The new Series 8573/13 compact socket replaces Series 8575 sockets, is 100% compatible with this series and can be used with Series 8575 plugs. |
Explosion Protection
Electrical Data
Device Specific Data
Ambient Conditions
Mechanical Data
Mounting / Installation
Components
Commercial data
