22" Panel PC / Thin Client, Application range (zones): 1/2/21/22
- Product Type: ORCA OS E59A
Technical data
General
| MY R. STAHL | ORCAPCTCOSA |
| Product Type | ORCA OS E59A |
| Highlights | Modular Panel PC / Thin Client Operator Station, 22" displayZone 1, 21, Class I, Zone 1 / Div 2, stainless steel enclosure IP66, GMP compliantRobust touch screen, protected behind reflection-free glassData transmission via Ethernet copper up to 100 m and / or glass fibre up to 10 km |
| Functional Description | The ORCA E59A Operator Stations are modular explosion-proof Panel PCs or Thin Clients for zones 1 and 21. Their brilliant 22-inch widescreen displays with robust multi-touch capable touch screen have a resolution of 1920 x 1080 pixels (format 16:9). The enclosures in SS304 or SS316L stainless steel are available with front opening in cleanroom-compatible design, also in different mounting variants. You can configure country-specific keyboards, pointing instruments, RFID readers and barcode readers, processors, memory variants, interfaces as well as SSDs. Data transmission is via Ethernet as 10/100/1000Base-TX, 1000Base-SX or 1000Base-LX. |
| Series | ORCA Operator Stations for indoor and protected outdoor |
| Product description | 22" Panel PC / Thin Client |
| HMI type | Operator station |
| Technology | Panel PCs / Thin Clients |
Explosion Protection
Electrical Data
Display
Ambient Conditions
Mechanical Data
Mounting / Installation
Components
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| Panel PC / Thin Client Device platform ORCA - ORCA OS E59A - de-DE | Single Data Sheet |
 |
|
| Panel PC / Thin Client Device platform ORCA - ORCA OS E59A - en-GB | Single Data Sheet |
 |
|
| Panel PC / Thin Client Device platform ORCA - ORCA OS E59A - en-US | Single Data Sheet |
  |
