Series 7571/11 32 A wall-mounting sockets
Art. No.:
126462
Product Type:
7571/11-405
Product Description:
Wall-mounting socket 32 A
max. ambient temperature:
+40 °C
min. ambient temperature:
-30 °C
Entry 1 type:
8161/7-M32-2109
Entry 2 type:
8290/3-M32
Rated operational current:
32 A
Frequency range:
50 / 60 Hz
Silicone-free:
Yes
Colour code:
black
Coding (clock hour position):
5
Detailed number of poles:
3 P + PE
Country of origin:
DE
On request
Technical data
General
MY R. STAHL | 7571A |
Product Type | 7571/11-405 |
Product Description | Wall-mounting socket 32 A |
Highlights | For use in Zones 2 and 22, IP66 in every application positionOptional auxiliary contacts for control and signalling purposesWith AC-3 motor switching capacity according to IEC/EN 60947-3 |
Functional Description | R. STAHL Series 7571/11 SolConeX sockets offer full AC-3 switching capacity up to 32 A for Zones 2 and 22. Self-cleaning lamellar contacts provide optimum contact and the floating pins allow the plugs to be inserted and removed in the zero position with minimum effort. The load disconnect switch, with a mechanical locking device and a handle that can be locked in the 0 or I position, is an additional safety feature. |
Explosion Protection
Electrical Data
Device Specific Data
Ambient Conditions
Mechanical Data
Mounting / Installation
Components
Commercial data
Downloads
Description | Document Type | Language | |
---|---|---|---|
Plugs and Sockets Series 7570, 7571, 7575, 7579, 7581 | Data Sheet |
![]() |
|
Plugs and Sockets Series 7570, 7571, 7575, 7579, 7581 | Data Sheet |
![]() |
|
Wall-mounting socket 32 A - 7571/11-405 - 126462 - de-DE | Single Data Sheet |
![]() |
|
Wall-mounting socket 32 A - 7571/11-405 - 126462 - en-GB | Single Data Sheet |
![]() |
|
Wall-mounting socket 32 A - 7571/11-405 - 126462 - fr-FR | Single Data Sheet |
![]() |
|
Wall-mounting socket 32 A - 7571/11-405 - 126462 - es-ES | Single Data Sheet |
![]() |
