TRANBERG® Searchlight Commander Control Panel Series TEF2612
- Product Type: TEF2612113120
- Art. No.: 242232
Technical data
General
| MY R. STAHL | T2612A |
| Product Type | TEF2612113120 |
| Product description | Commander Searchlight control Master panel for TEF 2650 searchlight |
| Highlights | Compact sizeDimmable backlightingLarge pushbuttons for easy and secure operationEasy installationOperated at a safe 24VDCOperates one searchlight“Home” function allows the user to predefine a default position, and to return to this position with a single press on this button |
| Functional Description |
TEF 2612 is a new type of control panel for searchlights. With this panel you can control one searchlight. Up to 8 panels can be connected to the network. This type of panel can only be used together with searchlights which is adapted to this kind of technology. The searchlights and the control panels are connected to a common RS-485 network, which reduce the wiring on the vessel to a minimum. APPLICATION: For flush mounting. Up to 8 panels may be connected to the network. May be used with any kind of light source. TEF 2618 radio control interface may be connected to the network |
Explosion Protection
Electrical Data
Auxiliary power
Diagnostics
Display
Mechanical Data
Components
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| TRANBERG® Commander - TEF2612 - de-DE | Product Overview |
 |
|
| TRANBERG® Commander - TEF2612 - en-GB | Product Overview |
 |
|
| Commander Searchlight control Master panel for TEF 2650 searchlight - TEF2612113120 - 242232 - de-DE | Single Data Sheet |
|
|
| Commander Searchlight control Master panel for TEF 2650 searchlight - TEF2612113120 - 242232 - en-GB | Single Data Sheet |
|
