8082C3-11-1-0-1, Disconnect terminal for installation on mounting rail, 1 NC, Screw terminal, Contact material: Silver-nickel, Zone 1/2
- Product Type: 8082C3-11-1-0-1
- Art. No.: 349417
Technical data
General
| MY R. STAHL | 8082E |
| Product Type | 8082C3-11-1-0-1 |
| Highlights | 1-pole, positive opening NC contactFor installation in Ex e enclosuresClear position indicationActuator can be locked in the zero positionConnection cross-section: 0.75 to 2.5 mm², solid/finely strandedEnclosure made of polyamide |
| Functional Description | Series 8082 disconnect terminals can be used to disconnect electrical circuits for maintenance and test purposes. The disconnect terminals are used in Ex e enclosures and may also be actuated in hazardous areas while live. When the contact is open, the supply line clamping unit is covered.The actuator can be locked with a padlock in the zero position according to IEC/EN 60947-5-1. Using special DIN rails which are available as accessories, the devices can be arranged next to each other to form blocks. |
Explosion Protection
Electrical Data
Ambient Conditions
Mechanical Data
Mounting / Installation
Components
Commercial data
Downloads
